Jel( Jel Elektrolit ) Tip Aküler


Voltage: 2V, 6V, 12V  Capacity: FP Type: 12V12AH~12V28AH ; LFP Type: 12V33AH ~ 12V250AH; CFP Type: 2V100AH~2V3000AH   Charge voltage: Cycle use: 2.30~2.35V/cell; Float use: 2.25~2.30V/cell   Charge current: The initial current less then 0.3CA

Gel Battery Summary

The FirstPower gel battery uses the sealed gel technology and is designed for high reliable, maintenance-free power for renewable energy applications. Depending on the advantage gel technology, optimum grid and plate design, the FirstPower gel battery offers highest power and reliability for your equipments.

Typical Applications

  • Water pumping
  • Cathodic protection
  • Communications
  • Solar & Windsystem
  • Electric powered vehicles
  • Golf cars
  • Commercial deep cycle applications
  • Power plant
  • UPS systems




Model Nominal
Voltage
(V)		 Capacity
(AH)		 Internal
Resistance
(mOhm)		 Dimensions（mm/in） Terminal Weight
±4%(Kg)
Length Width Height Total Height
mm in mm in mm in mm in Type Position Kg Lbs
FPG12180 12 18 16 181 7.13 77 3.03 167 6.57 167 6.57 T8 C 5 11.02
FPG12240 12 24 20 166 6.54 175 6.89 125 4.92 125 4.92 T8 C 7.4 16.31
FPG12280 12 28 15 8 17.64
FPG12280A 12 28 14 165 6.5 125 4.92 175 6.89 175 6.89 T8 C 9 19.84
LFPG6100 6 100 3.3 194 7.6 170 6.7 205 8.1 205 8.1 T9 A 15.8 34.83
LFPG6190 6 190 2.2 243 9.6 187 7.4 253 10 276 10.9 T11 A 31 68.34
LFPG1233 12 33 11 195 7.7 130 5.1 155 8.9 155 8.9 T9 C 10.2 22.49
LFPG1240 12 40 9.5 197 7.8 165 6.5 170 6.7 170 6.7 T9 D 12.5 27.56
LFPG1255 12 55 7 229 9 138 5.4 208 8.2 208 8.2 T9 C 17 37.48
LFPG1265 12 65 6.6 350 3.8 167 6.6 179 7 179 7 T9 C 21 46.30
LFPG1260 12 60 7.7 22 48.50
LFPG1270 12 70 7 260 10.2 168 6.6 211 8.3 211 8.3 T9 C 24 52.91
LFPG1280 12 80 6.5 306 12.05 169 6.65 211 8.3 211 8.3 T9 C 27.5 60.63
LFPG1290 12 90 5.8 306 12.05 169 6.65 211 8.3 211 8.3 T9 C 28.5 62.83
LFPG1290H 12 90 5.4 330 13 171 6.7 214 8.4 214 8.4 T9 C 31 68.34
LFPG12100 12 100 5 330 13 171 6.7 214 8.4 214 8.4 T9 C 32 70.55
LFPG12110 12 110 5.2 330 13 171 6.7 225 8.86 225 8.86 T9 C 33.5 73.85
LFPG12120 12 120 4.4 409 16.1 176 6.9 225 8.9 225 8.9 T11 C 36.5 80.47
LFPG12140 12 134 4.2 342 13.5 172 6.8 280 11 280 11 T11 C 42.5 93.70
LFPG12150 12 150 3.9 485 19.1 172 6.8 240 9.4 240 9.4 T11 C 44 97.00
LFPG12180 12 180 3.6 494 19.4 206 8.1 209 8.2 209 8.2 T11 C 55 121.25
LFPG12160 12 160 3.2 530 20.8 207 8.15 214 8.43 214 8.43 T11 C 53 116.84
LFPG12200 12 200 3.3 522 20.6 238 9.4 218 8.6 218 8.6 T11 C 66 145.51
LFPG12250 12 250 2.9 521 20.5 269 10.6 220 8.7 220 8.7 T11 E 75 165.35
LFPG1250FT 12 50 7.2 277 10.91 106 4.17 221 8.7 221 8.7 T9 E 17 37.48
LFPG12100FT 12 100 5.4 506 19.9 110 4.3 224 8.8 239 9.4 T9 E 31 68.34
LFPG12150FT 12 150 4 551 21.7 110 4.3 287 11.3 287 11.3 T11 E 47 103.62
LFPG12180FT 12 180 3 546 21.5 125 4.9 317 12.5 323 12.7 T11 E 57 125.66
CFPG2100 2 100 0.9 171 6.7 72 2.8 206 8.1 209 8.2 T10 A 6 13.23
CFPG2150 2 150 0.7 171 6.7 102 4 206 8.1 211 8.3 T10 A 8.5 18.74
CFPG2200 2 200 0.95 173 6.8 109 4.3 330 8.3 364 14.3 T10 G 14 30.86
CFPG2300 2 300 0.8 171 6.7 151 5.9 330 8.3 364 14.3 T10 G 19.5 42.99
CFPG2400 2 400 0.65 210 8.3 176 6.9 330 8.3 367 14.4 T10 H 26.5 58.42
CFPG2500 2 500 0.55 241 9.5 171 6.7 330 8.3 365 14.4 T10 H 31.5 69.45
CFPG2600 2 600 0.5 302 11.9 175 6.9 330 8.3 367 14.4 T10 H 38 83.78
CFPG2800 2 800 0.4 410 16.1 175 6.9 330 8.3 367 14.4 T10 I 53.5 117.95
CFPG21000 2 1000 0.3 475 18.7 175 6.9 330 8.3 367 14.4 T10 I 64 141.10
CFPG21500 2 1500 0.22 400 15.7 350 13.8 345 13.6 382 15 T10 J 97 213.85
CFPG22000 2 2000 0.2 490 19.3 350 13.8 345 13.6 382 15 T10 K 130 286.60
CFPG23000 2 3000 0.13 710 28 350 13.8 345 13.6 382 15 T10 K 198 436.52
CFPG2200S 2 200 0.9 206 8.1 103 4.1 355 14 390 15.4 T10 G 15.5 34.17
CFPG2250S 2 250 0.8 206 8.1 124 4.9 355 14 390 15.4 T10 G 19 41.89
CFPG2300S 2 300 0.75 206 8.1 145 5.7 355 14 390 15.4 T10 G 21 46.30
CFPG2350S 2 350 0.7 206 8.1 124 4.9 471 18.5 506 19.9 T10 G 24 52.91
CFPG2400S 2 400 0.6 206 8.1 145 5.7 471 18.5 506 19.9 T10 G 27.5 60.63
CFPG2500S 2 500 0.5 206 8.1 166 6.5 471 18.5 506 19.9 T10 G 32 70.55
CFPG2600S 2 600 0.45 206 8.1 145 5.7 646 25.4 681 26.8 T10 G 43 94.80
CFPG2800S 2 800 0.4 210 8.3 191 7.5 646 25.4 681 26.8 T10 H 60 132.28
CFPG21000S 2 1000 0.33 233 9.2 210 8.3 646 25.4 681 26.8 T10 H 71 156.53
CFPG21200S 2 1200 0.28 275 10.8 210 8.3 646 25.4 681 26.8 T10 H 87 191.80
CFPG21500S 2 1500 0.22 275 10.8 210 8.3 796 31.3 831 26.8 T10 H 105 231.49
CFPG22000S 2 2000 0.2 399 15.7 210 8.3 772 30.4 807 31.8 T10 I 150 330.69
CFPG22500S 2 2500 0.17 487 19.2 212 8.3 772 30.4 807 31.8 T10 I 187 412.26
CFPG23000S 2 3000 0.13 576 22.7 212 8.3 772 30.4 807 31.8 T10 I 223 491.63
